*1: When note sizes are common among handling denominations.
| Installation | Frontload / Rearload types for lobby use |
|---|---|
| Dimensions | (W) 416 x (D) 859 x (H) 857mm |
| Capacity | Cash In Tray: 300notes. w/ continuous deposit |
| Cash Out Slot: 100notes. | |
| Escrow: - (No escrow) *2 | |
| Cassettes (Single room): 362mm (Max. 3,400notes.*1) |
|
| Cassettes (Dual rooms): 55mm + 200mm (Max. 450notes. + 1,800notes. *1) |
|
| Retract Box: - | |
| Storage | Up to 5 lanes for Single or Dual room cassettes (Max. 8 recycling + 2 deposit only rooms) |
| Communication Interface |
USB 2.0 |
| Power | DC 24V |
| Options | Optional Shutter for Cash out Slot |
| Cassette withdrawal Lock Kit for CIT operations |
*1: In the case of Japanese mint conditioned notes. Number of notes may vary depending on the thickness and condition of notes.
*2: One of the Dual Recycling Cassette rooms can be used as escrow when note sizes are common among handling denominations.
