It is optimized for high performance, enhanced authentication and easy operation.
| [Product Features] - Speedy operation (1200notes/min) - Large cassette capacity (7,000 notes, 12,000 notes) - Remote Management System (RMS program) - Full Color LCD 15”, touch screen - User customizing option (Coin deposit, Barcode reader, Card reader, Spare Cassette, Encrypting PIN Pad etc.) |
|||
|
|
|
||
|---|---|---|---|
| System Control |
• OS : Windows 10 | ||
| • Battery backup | |||
| Operation | • LCD : 15” Swing (IR Touch screen) | ||
| Input Device |
• Card reader (Option - Motor driven) | ||
| • Barcode reader (Option - 1D / 2D) | |||
| • Camera : Face | |||
| • PIN pad (Option) | |||
| Output Device |
• Receipt Printer-NTPR 080CU | ||
| • Online (LAN) | |||
| Processing | • ST-150NV Counterfeit Detector | ||
| • Speed : 1,200 notes/min. | |||
| • Escrow : EDM-3 Belt feeding & bundle | |||
| • Escrow capacity : Max 200 notes | |||
| • Valid banknote: Customized | |||
| Safety | • Japan Level3 correspondent | ||
| • Electronic lock (Dial lock Option) | |||
| • Sub-door | |||
| Saving | • Aluminum cassette box(Max 7,000 notes) | ||
| • Bag-type cassette(Max 12,000 notes) | |||
| Dimension | • 470(W) X 562(D) X 1,569(H) | ||
| • Power : 1. MCPM SMPS - PSC-60A | |||
| 115VAC / 1.6A | |||
| 230VAC / 1A | |||
| 2. Device SMPS - ADD-155B | |||
| 115VAC / 2.5A | |||
| 230VAC / 1.5A | |||
